Low frequency trigger QW-2125
Description
Low frequency trigger QW-2125
Product Introduction:
125KHz trigger QW-2125, using LC oscillation circuit technology, is used to wake up the tag and make the tag in the triggered state. The trigger can adjust the trigger distance, which is convenient for users to adjust according to the actual situation; different address codes can also be set to prevent mutual interference between adjacent triggers. The 125KHz trigger QW-2125 is very suitable for indoor application environment, and cooperates with the 2.4GHz reader to realize the regional positioning of the target
Product Feature:
- Integrated design, beautiful appearance, easy installation;
- The trigger distance is adjustable, ranging from 1 to 3 meters;
- Low voltage power supply, DC5V;
Product Parameters:
| RF parameters | |
| Working Frequency | 125khz |
| Antenna Direction | omnidirection |
| Trigger Distance | 1-3m |
| Electrical parameters | |
| Operating Voltage | DC 5V |
| Working current | <100mA/DC5V |
| Physical parameters | |
| Working Temp | -20℃ to +60℃ |
| Storage Temp | -40℃ to +80℃ |
| Working humidity | 5% ~ 95%(无凝露) |
| Dimensions (R x D) | 105*105*25mm |
| Weight | 0.2kg |
| Material | ABS |
